SP5000 Series
Lineup / Specifications
Module Configuration
| Premium Display | Advanced Display | Open Box | Power Box | Standard Box |
|---|---|---|---|---|
|
Industry's top-class display with high display quality and versatile functions |
Sophisticated display with high display quality |
Enable to use Windows Applications via HMI |
Reliable real-time OS installed in HMI High performance & Extended HMI |
Reliable real-time OS installed in HMI High performance HMI |
|
SP-5800WC SP-5700WC SP-5700TP SP-5660TP (End of Sale: Jun 30, 2025) SP-5600TP SP-5500TP |
SP-5600TA SP-5600WA SP-5500WA SP-5400WA |
SP-5B41 (End of Sale: Apr 30, 2025) SP-5B411 SP-5B412 | SP-5B10 | SP-5B00 |
| Specifications about Display Module | Specifications about Box Module | |||
Display Module
| Display Type | Product Name | Model No. | Display Size | Display Colors | Touch Panel Type | Front USB | Brightness Sensor | Auto Scaling | Details |
|---|---|---|---|---|---|---|---|---|---|
| Premium | SP-5800WC *1 | PFXSP5800WCD | 19" Wide (FWXGA) | 16 million |
Projected Capacitive (multi-touch) | Yes | Yes | Yes |
Datasheet (PDF) |
| SP-5700WC *1 | PFXSP5700WCD | 15" Wide (FWXGA) | |||||||
| SP-5700TP | PFXSP5700TPD | 15" (XGA) |
Analog Resistive Film (multi-touch) | ||||||
|
SP-5660TP *2 (End of Sale: Jun 30, 2025) | PFXSP5660TPD | 12" (XGA) | |||||||
| SP-5600TP | PFXSP5600TPD | 12" (XGA) | |||||||
| SP-5500TP | PFXSP5500TPD | 10" (SVGA) | |||||||
| Advanced | SP-5600TA | PFXSP5600TAD | 12" (XGA) | 262,144 |
Analog Resistive Film | No | No | No | |
| SP-5600WA | PFXSP5600WAD | 12" Wide (WXGA) | |||||||
| SP-5500WA | PFXSP5500WAD | 10" Wide (WXGA) | |||||||
| SP-5400WA | PFXSP5400WAD | 7" Wide (WVGA) |
-
- *1
- SP-5800WC, SP-5700WC and SP-5600TA are not compatible with SP-5B40 (End of Sale: Mar. 30, 2018).
-
- *2
- SP-5660TP is not compatible with SP-5B10 (Power Box) and SP-5B00 (Standard Box).
Box Module
| Box Type | Product Name | Model No. | Windows Application | Expansion Unit | Sound Output | AUX Output | Details | |
|---|---|---|---|---|---|---|---|---|
| Open | WES 7 |
SP-5B41 *3 (End of Sale: Apr 30, 2025) | PFXSP5B41* | Yes | Yes | Yes | Yes |
Datasheet (PDF) |
| Windows 10 (HMI Runtime not included) | SP-5B411 *4 | |||||||
| Windows 10 (HMI Runtime included) | SP-5B412 *4 | |||||||
| Power | SP-5B10 *5 | PFXSP5B10 | - | |||||
| Standard | SP-5B00 *5 | PFXSP5B00 | - | - | - | |||
-
- *3
- Microsoft ended Support for Windows Embedded Standard 7 on October 10th 2023 - No OS Updates can be applied to SP5B41
- *4
- Microsoft will end Support for Windows 10 IoT Enterprise 2019 LTSC on January 9th 2029 - No OS Updates will be available for SP5B411 & SP5B412 after this date
- *5
- SP-5B10 (Power Box) and SP-5B00 (Standard Box) are not compatible with SP-5660TP.
Display Module x Box Module
For Dimensions Drawings and Mounting & Clearance information, please refer to the user manual.
| Screen Size | Image | Product Name | Bright- ness Sensor/ Auto Scaling/ Front USB/ Multi- touch | Win- dows Apps | Video/ Sound | Remov- able System | CFast (Stor- age) | SD (Stor- age) | USB Type A | USB mini B | SIO | Ether -net | Rated Voltage | Details |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 19" Wide (FWXGA) |
|
SP-5800WC + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5800WC + SP-5B10 | Yes | - | - | Yes | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5800WC + SP-5B00 | Yes | - | - | - | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 15" Wide (FWXGA) |
|
SP-5700WC + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5700WC + SP-5B10 | Yes | - | - | Yes | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5700WC + SP-5B00 | Yes | - | - | - | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 15" (XGA) |
|
SP-5700TP + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5700TP + SP-5B10 | Yes | - | - | Yes | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5700TP + SP-5B411 / SP-5B412 | Yes | - | - | - | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 12" (XGA) Wireless LAN Model |
|
SP-5660TP (End of Sale: Jun 30, 2025) + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
| 12" (XGA) |
|
SP-5600TP + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5600TP + SP-5B10 | Yes | - | - | Yes | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5600TP + SP-5B00 | Yes | - | - | - | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 12" (XGA) |
|
SP-5600TA + SP-5B411 / SP-5B412 | - | Yes | Yes | Yes | x 1 | x 1 | x 3 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5600TA + SP-5B10 | - | - | - | Yes | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5600TA + SP-5B00 | - | - | - | - | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 12" Wide (WXGA) |
|
SP-5600WA + SP-5B411 / SP-5B412 | - | Yes | Yes | Yes | x 1 | x 1 | x 3 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5600WA + SP-5B10 | - | - | - | Yes | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5600WA + SP-5B00 | - | - | - | - | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 10" (SVGA) |
|
SP-5500TP + SP-5B411 / SP-5B412 | Yes | Yes | Yes | Yes | x 1 | x 1 | x 4 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5500TP + SP-5B10 | Yes | - | - | Yes | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5500TP + SP-5B00 | Yes | - | - | - | - | x 1 | x 3 | x 2 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 10" Wide (WXGA) |
|
SP-5500WA + SP-5B41 (End of Sale: Apr 30, 2025) | - | Yes | Yes | Yes | x 1 | x 1 | x 3 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5500WA + SP-5B10 | - | - | - | Yes | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5500WA + SP-5B00 | - | - | - | - | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
| 7" Wide (WVGA) |
|
SP-5400WA + SP-5B411 / SP-5B412 | - | Yes | Yes | Yes | x 1 | x 1 | x 3 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
|
SP-5400WA + SP-5B10 | - | - | - | Yes | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box | ||
|
SP-5400WA + SP-5B00 | - | - | - | - | - | x 1 | x 2 | x 1 | x 2 | x 2 | 12 to 24 Vdc | Display/ Box |
Bezel Color
Front Color
| Front Color | Black | Silver |
|---|---|---|
| Front Panel |
Black (RAL7016) |
Silver (PANTONE 8401C) |
| Front Bezel | Black | Standard (Silver) |
Coating*6
Peace of mind in a harsh environment. "Coated models" feature more protection from corrosion.
Extended product lifetime for use in harsh environments compared to uncoated products. Corrosion resistance is also improved.
-
- *6
- Except for SP-5800WC and SP-5700WC.
