BLUE Open Studio

Flexible Software

Pro-face BLUE Open Studio is a development and runtime software that incorporates all of the tools users need to create SCADA HMI applications, dashboards and OEE interfaces.


Introduction Movie

The videos explain about what BLUE Open Studio is. Watch the videos and make the most of BLUE Open Studio.

Features

Connectivity

  • Native OPC interfaces such as OPC UA/DA
  • Active X and .Net controls
  • 250+ available communication drivers for PLCs and many other devices.
  • Support upper connectivity to DB through MQTT.


Mobility

Access to the system from anywhere using a single browser.



Reliability

Take advantage of built-in features to develop 21 CFR part11 compliant application.



License Lineup

License level can be selected to meet your needs.

Product Name No. of
Licenses
No. of
Tags
Model Media
BLUE Open Studio for Supervision Build time 1 License 64,000 PFXBOSBT64KDV80 DVD
PFXBOSBT64KLV80 Sticker
Runtime PFXBOSRT64KLV80
BLUE Open Studio for Supervision for 3rd Party PC PFXBOS3PRT64KLV80
Upgrade License from Line Mnagement Plus to Supervision Build time PFXBOSUG64KBT
Runtime PFXBOSUG64KRT
Upgrade from Line Management Plus to Supervision for 3rd Party PC PFXBOS3PUG64KRT
BLUE Open Studio for Line Management Plus Build time 32,000 PFXBOSBT32KDV80 DVD
PFXBOSBT32KLV80 Sticker
Runtime PFXBOSRT32KLV80
BLUE Open Studio for Supervision for 3rd Party PC PFXBOS3PRT32KLV80
Upgrade License from Line Mnagement to Line Mnagement Plus Build time PFXBOSUG32KBT
Runtime PFXBOSUG32KRT
Upgrade from Line Management to Line Management Plus for 3rd Party PC PFXBOS3PUG32KRT
BLUE Open Studio for Line Management Build time 4,000 PFXBOSBT4KDV80 DVD
PFXBOSBT4KLV80 Sticker
Runtime PFXBOSRT4KLV80
BLUE Open Studio for Line Management for 3rd Party PC PFXBOS3PRT4KLV80
Upgrade License from Machine Control to Line Mnagement Build time PFXBOSUG4KBT
Runtime PFXBOSUG4KRT
Upgrade from Machine Control to Line Management for 3rd Party PC PFXBOS3PUG4KRT
BLUE Open Studio for Machine Control Build time 1,500 PFXBOSBT1KDV80 DVD
PFXBOSBT1KLV80 Sticker
Runtime PFXBOSRT1KLV80
BLUE Open Studio for Machine Control for 3rd Party PC PFXBOS3PRT1KLV80
BLUE Open Studio Mobile Access - 8 Licenses - PFXBOSMA8LV80
4 Licenses PFXBOSMA4LV80
Upgrade License Mobile Access from 4 to 8 PFXBOSUG8MA
BLUE Open Studio Secure Viewer PFXBOSSV4LV80
BLUE Open Studio USB Hard key - PFXBOSUSBL
PanelBuilder Import Wizard 1 License PFXBOSPBTK
PanelBuilderMate Import Wizard PFXBOSPMTK
PanelBuilder Import Wizard PFXBOSPTTK

Database Availability

Database interface can be configured easily via standard technologies.

Type of Database BLUE Open Studio
Microsoft SQL Server
Jet 4.0
Access DB Engine
Analysis Services 12.0
Analysis Services 9.0
Data Mining Services
Indexing Service
ODBC Drivers
OLAP Services 8.0
Oracle
Search
Simple Provider
MS Data Shape
Microsoft Directory Services
SQL Server Native Client 11.0

OPC Server Client Availability

BLUE Open Studio includes OPC server clients as standard features.

  BLUE Open Studio
Server/Client OPC DA 3.0 -
OPC DA 2.05
Server OPC HAD
Client OPC UA
OPC.net
OPC XML

Supported Models

PS5000 Series

Product Name Screen Size  OS Storage Media Specifications Supported
Software Version
PS-5900W 22" Wide
(FWXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i7 Model Ver. 8.00 or later
Celeron Model
PS-5800W 19" Wide
(FWXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i7 Model Ver. 8.00 or later
Celeron Model
PS-5700W 15" Wide
(WXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i7 Model Ver. 8.00 or later
Celeron Model
PS-5700T 15"
(XGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i7 Model Ver. 8.00 or later
Celeron Model
PS-5000B - Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i7 Model Ver. 8.00 or later
Celeron Model Ver. 8.00 or later
PS-5811W 19" Wide
(FWXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i3 Model Ver. 8.00 or later
PS-5821W 19" Wide
(FWXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i3 Model Ver. 8.00 or later
PS-5711W 15" Wide
(WXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Core i3 Model Ver. 8.00 or later
PS-5701W 15" Wide
(WXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Atom Model Ver. 8.00 or later
PS-5501W 10" Wide
(WXGA)
Windows® 7 Ultimate (64 bit)
Windows® Embedded Standard 7 (32 bit/64 bit) MUI
Windows® Embedded 8.1 Industry (64 bit)
Windows® 10 IoT Enterprise 2016 LTSB (64 bit)
HDD
SSD
CFast Card
Atom Model Ver. 8.00 or later

SP5000 Series

Product Name Screen Size  OS Storage Media Specifications Supported
Software Version
SP-5800WC
+
SP-5B41S8A
19" Wide
(FWXGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5700WC
+
SP-5B41S8A
15" Wide
(FWXGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5700TP
+
SP-5B41S8A
15"
(XGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5660TP
+
SP-5B41S8A
12"
(XGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5600TP
+
SP-5B41S8A
12"
(XGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5500TP
+
SP-5B41S8A
10"
(SVGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5600WA
+
SP-5B41S8A
12" Wide
(WXGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5500WA
+
SP-5B41S8A
10" Wide
(WXGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
SP-5400WA
+
SP-5B41S8A
7" Wide
(WVGA)
Windows® Embedded Standard 7 Premium (32 bit) MUI CFast
SD
Display / Box Ver. 8.02 or later
