What is the PS6000 Series?

PS6000_what_top

PS6000 Series makes the next stage of your digital transformation.

New PS6000 Series from the HMI leader: Robust as a terminal, Open and High-performant as a PC, even more economical.
You have an increasing need for data management and flexibility with smart manufacturing, digitization, IIoT, Edge computing.
PS6000 brings high-end HMI capabilities, building PC-based architecture from the needs of the application, selecting software, system structure, operation efficiency, data flow.
PS6000 makes the next stage of your digital transformation and new experience, providing flexibility, simple visibility, and reliability.



Selection Guide



Standard Box

(Core i3)

Advanced Box

(Core i7 / Core i5 / Celeron)

UI design and integrate application software for operator terminal
(Powered by BLUE Open Studio)
ps6000_star

Use together with other software and connect to IT system
(Powered by BLUE Open Studio including Data Base functionalities.)

ps6000_star

Remote Visualization on PC or Tablet
(Powered by BLUE Open Studio Thin Client License or Pro-face Remote HMI Client for Win)

Secure remote connect
(Powered by Pro-face Connect)

Smart Maintenance
(Powered by EcoStruxure Augmented Operator Advisor)

ps6000_star

Simple field connections
(Compact operator panel)

ps6000_star

Wide field connections
(Several controllers connection)

ps6000_star




Feature

A new Experience for Automation Engineers from system design to commissioning (learn more)


A new Experience for Operators and Production Managers (learn more)


A new Experience for Maintenance Specialists
(learn more)


Lineup

ps6000_lineup
For more details, please access the Product Configurator. Easy to find your favorite configuration.

Box Module

Type OS*1 CPU DIM Storage Interface

Slot-in Option I/F

Expansion slots

Details

Advanced Box*2

Windows10 IoT
Enterprise
2019 LTSC
(64bit)

Core i7

8 - 32GB

M.2 SSD x1
2.5" HDD/SSD x2

RS-232C x1,
USB Type A: USB2.0 x2, USB3.0 x2,
USB Type C: USB3.0 x1,
Ethernet(RJ45) x2,
DisplayPort x1

2 slots

PCI x1 + PCIe x1
or
PCIe x2
or
PCI x 2

Specification

Core i5

Specification

Celeron

4 - 16GB

Specification

Standard Box

Core i3

8 - 32GB

M.2 SSD x1
2.5" HDD/SSD x1

1 slots - Specification




The basic model (PS5000 Series Atom model) is now also available.


Display Module



Display Size

Resolution

Display Type Touch Panel Type

Touch Mode Configuration

Front USB

Details
NEW 22" Wide

Full HD
(1,920 x 1,080)

TFT Color LCD

Capacitive Multi-touch
with optimized noise filer

Yes

-Standard mode
-Glove mode,
-Water detection mode

- Specification
19" Wide Specification
15" Wide FWXGA
(1,366 x 768)
Specification
NEW 12" Wide WXGA
(1,280 x 800)
Specification
NEW 10" Wide *1  Specification
15"

XGA
(1,024 x 768)

Resistive multi-touch

Not applicable,
because of a resistive analog touch panel

USB(Type A) x1*2

Specification
12" Specification

*1 10" Wide is available with only Standard Box, not supported for Advanced Box.

*2 By default, the USB is disabled
