Display type
Colour TFT LCD
Display colour
16 million colours
Display resolution
800 x 600 pixels SVGA
Touch panel
Multi touch analogue resistive
Backlight lifespan
50000 hours with white
Brightness
101 levels via touch panel
Character font
Japanese
ASCII
Chinese (simplified Chinese)
Chinese (traditional Chinese)
Korean
Cyrillic
Thai
[Us] rated supply voltage
100...240 V AC
Input voltage limits
85...264 V AC
Rated short-duration power frequency withstand voltage
1.5 kV AC during 1 min
Local signalling
Status LED green, steady for operating
Memory description
Built in flash memory 4 GB
Memory description
Backup memory NVRAM 512 KB
Type of cooling
AN (air natural)
Integrated connection type
USB 2.0 port USB type A
USB 2.0 port micro B USB
Ethernet 2 RJ45, interface: 10 BASE-T/100 BASE-TX/1000 BASE-T
COM1 serial link 1 SUB-D 9-pin male, interface: RS232C, transmission rate: 2400...115200 bps
COM2 serial link 1 SUB-D 9-pin male, interface: RS422/RS485, transmission rate: 2400...115200 bps
COM2 serial link 1 SUB-D 9-pin male, interface: RS422/RS485, transmission rate: 187.5 kbps compatible with MPI
SD/SDHC/SDXC
Electrical connection
Cable 2 mm², 14 AWG, max resistance 100 Ohm for protective earth
Fixing mode
By 4 installation fasteners, mounting on 1.6...5 mm thick panel
Cut-out dimensions
259 x 201 mm panel cut dimension
