Create HMI Overlays

Process | Create | Submit | Pricing | Contact

Step 1
Download Template
Step 2
Create Your Overlay
Step 3
Submit to Pro-face

Select a Pro-face product and download one of our templates to assist in creating your custom overlay artwork. Products currently available for Custom Overlays are the STW6000 Series, ST6000 Series, STM6000 Series, GP-4000 Series, LT-4000 Series, and SP-5000 Series HMIs. Overlays for the EZ Series USB Solutions are also available. (Minimum order of 10 pieces is required.)
Custom Logos are available for most Pro-face products.

Find Links to Overlay Template Below

Series	Model	Link
GP4100 Series	PFXGP4114T2D	View
	PFXGP4115T2D	View
	PFXGP4116T2D	View
GP4300 Series	PFXGP4301TAD	View
	PFXGP4301TADC	View
	PFXGP4303TAD	View
GP4400	PFXGP4401TAD	View
GP4500 Series	PFXGP4501TAA	View
	PFXGP4501TAAC	View
	PFXGP4501TAD	View
	PFXGP4501TADC	View
	PFXGP4501TMA	View
	PFXGP4501TMD	View
	PFXGP4503TAD	View
GP4600 Series	PFXGP4601TAA	View
	PFXGP4601TAAC	View
	PFXGP4601TAD	View
	PFXGP4601TADC	View
	PFXGP4601TMA	View
	PFXGP4601TMD	View
	PFXGP4603TAD	View
LT4000M Series	PFXLM4201TAD	View
LT4000M Series	PFXLM4301TAD	View
EZ Series	PFXZCCEUSG1	View
Custom Logos	1.60" x 0.80"	View
	1.00" x 0.28"	View
	2.00" x 0.60"	View
	2.00" x 0.45"	View
	2.05" x 0.55"	View
	2.17" x 0.77"	View
