Extract String (Middle)
Extracts a string from a desired position.
Block
Text
TARGET = substring(INPUT, STARTPOSITION, COUNT);
1 4
2 3
| # | Description |
| 1 | [Destination Data]
Set the destination where you want to store the extracted string. |
| 2 | [Start position]
Integer value that specifies the start point for string extraction. The value must be greater than or equal to 1 and less than or equal to the extractable start position. |
| 3 | [Number of characters]
Set the number of characters to extract. The value must be greater than or equal to 1, and less than or equal to the number of characters that can be extracted. Double-byte characters are counted as a single character. |
| 4 | [Source Data]
Set the source data where the string to extract is stored. |
(Example)
Block
Text
Var4 = substring(Var3,Var5,Var1);
Operation Example
Variable in [Source Data] |
[Start position] |
[Number of characters] |
Variable in [Destination Data] |
Comments | |
Target string |
Maximum Number of Bytes | Extracted string to store | |||
| ABCDE | 2 | 3 | 5 | BCD | - |
| 4 | 3 | 5 | (none) |
A string is not stored because the [Number
of characters] exceeds the number of retrievable characters.
It is judged as fail in the "Operation Result" Operation.
|
|
| 6 | 3 | 5 | (none) |
A string is not stored because the [Start
position] exceeds the available start position. It is judged
as failed in the "Operation Result".
|
|
| 0 | 3 | 5 | (none) |
A string is not stored because the [Start
Position] is less than 1. It is judged as failed in the
"Operation Result".
|
|
| -1 | 3 | 5 | (none) |
A string is not stored because the [Start
Position] is less than 1. It is judged as failed in the
"Operation Result".
|
|
| 4 | 0 | 5 | (none) |
A string is not stored because the [Number
of characters] is less than 1. It is judged as fail in
the "Operation Result" Operation.
|
|
| 4 | -1 | 5 | (none) |
A string is not stored because the [Number
of characters] is less than 1. It is judged as fail in
the "Operation Result" Operation.
|
|
| 2.1 | 3 | 5 | BCD | The decimal part of the [Start Position] is truncated. | |
| 2 | 3.5 | 5 | BCD |
Values to the right of the decimal point in [Number
of characters] are dropped.
|
|
| ABCDEF | 1 | 6 | 5 | (none) |
A string is not stored because the converted string has exceeded the maximum
number of bytes that can be stored. It is judged as fail in the "Operation
Result" Operation.
|
| AB(0x00)CDE | 2 | 3 | 5 | (none) |
A string is not stored. If there is a NULL (0x00), the string is terminated
there. As a result, the [Number of characters] exceeds the number of retrievable
characters. It is judged as fail in the "Operation Result" Operation.
|
| 4 | 3 | 5 | (none) |
A string is not stored. If there is a NULL (0x00), the string is terminated
there. As a result, the [Start
position] exceeds the available start position. It is judged
as failed in the "Operation Result".
|
|
| AあB | 1 | 3 | 5 | AあB |
String is stored based on the [Number
of characters]. *1
|
| 2 | 3 | 5 | (none) |
A string is not stored because the [Number
of characters] exceeds the number of retrievable characters.
It is judged as fail in the "Operation Result" Operation.
|
|
| 2 | 2 | 5 | あB |
String is stored based on the [Number
of characters]. *1
|
|
*1 If the maximum number of bytes in the [Destination Data] variable is less than the size of the retrieved string, the operation will fail. The maximum number of bytes depends on the encoding of the [Destination Data] variable.
