Convert Numeric to String

Converts a numeric value (decimal or hexadecimal) to a string.

The number in [Source Data] is converted to a string in the data format (decimal or hexadecimal) specified in [Source Data Format] and stored in [Destination Data].

Block

Text

TARGET = toString(EXPRESSION, 10, 0);
1 5 2 3/4

Description

[Destination Data]

Set the destination where you want to store the converted string.

[Source Data Format]

Select one of the following formats:

Block

[Decimal]: Converts a decimal number to a string.
[Hex]: Converts a hexadecimal number to a string.

Text

'10': Converts a decimal number to a string.
'16': Converts a hexadecimal number to a string.

[Zero Suppress]

Block

Select the check box to suppress displaying zeros at the front of values.
Clear the check box to specify the number of [Integer Digits], and to add zeros at the front of values to align with the number of digits.

(Example) [Source Data]: 25, [Integer Digits]: 4
When check box is selected (enabled):	25
When check box is cleared (disabled):	0025

Text

Set '0' to suppress displaying zeros at the front of values.
Set a numeric value between '1' and '20' to specify the number of [Integer Digits], and to add zeros at the front of values to align with the number of digits.

(Example) [Source Data]: 25
[Integer Digits]: 0	25
[Integer Digits]: 4	0025

[Integer Digits]
Specify the number of digits in the string to convert.
Setting Value Range: 1 - 20
When [Script Mode] is [Block], set this value when the [Zero Suppress] check box is cleared.

[Source Data]
Set the source data where the number to convert is stored.

(Example)

Block

Text

Var3=toString(Var1,10,0);

Operation Example

Variable in [Source Data]		[Zero Suppress]	[Integer Digits]	Variable in [Destination Data]		Comments
Data Type and Value	Format	[Zero Suppress]	[Integer Digits]	Maximum Number of Bytes	Converted string	Comments
INT: 100 (0x64)	Decimal	Enable	-	5	100	-
		Enable	-	1	(none)	A string is not stored because the converted string has exceeded the maximum number of bytes that can be stored. It is judged as fail in the "Operation Result" Operation.
		Disable	4	5	0100	"0" is added to align with the number of digits specified in [Integer Digits].
			2	5	100	Even if the value exceeds the [Integer Digits], sets the converted string.
			6	5	(none)	A string is not stored because the converted string has exceeded the maximum number of bytes that can be stored. It is judged as fail in the "Operation Result" Operation.
			6	Use [Variable length]	000100	"0" is added to align with the number of digits specified in [Integer Digits].
	Hex	Enable	-	5	64	-
		Enable	-	1	(none)	A string is not stored because the converted string has exceeded the maximum number of bytes that can be stored. It is judged as fail in the "Operation Result" Operation.
		Disable	4	5	0064	"0" is added to align with the number of digits specified in [Integer Digits].
		Disable	6	Use [Variable length]	000064	"0" is added to align with the number of digits specified in [Integer Digits].
INT: -100 (0xFF9C)	Decimal	Enable	-	5	-100	"-" Minus sign is supported.
	Decimal	Disable	4	5	-0100	"-" Minus sign is supported.
	Hex	Enable	-	5	FF9C	-
REAL: 100.00	Decimal	Enable	-	5	100	Only integer portion is converted.
REAL: 100.00	Hex	Enable	-	5	64	Only integer portion is converted.
REAL: 100.678	Decimal	Enable	-	5	100	Only integer portion is converted.
BOOL: true	-	-	-	5	True	-
BOOL: false	-	-	-	5	False	-

Note: Even though you set one of the following date type values as the [Source Data], the value is not converted in date/time format to a string. The value is converted in integer format to a string.

DATE
TIME
TIME_OF_DAY
DATE_AND_TIME

(Example) DATE_AND_TIME Variable

Date / Time Format: 8/19/2020 10:19:00 AM

Integer Format ([Source Data Format]: [Dec]): 1597799940

Integer Format ([Source Data Format]: [Hex]): 5F3C7E04
