Data Logging
The Data Logging operation logs data for the specified data logging
group.
For information on the naming convention and script keywords, refer to
the following.
Naming Conventions
Block
Text
recordLoggingGroup(LOGGINGGROUP);
2 1
1: Logging group
2: Operation
| [RecordLogging] |
Block
[RecordLogging]
Text
'recordLoggingGroup($DataLogging.LoggingGroup1);' |
Records data. |
| [ClearLogging] |
Block
[ClearLogging]
Text
'clearLoggingGroup($DataLogging.LoggingGroup1,
false);' |
Use [Optimize DB] option to optimize the database.
[Optimize DB] |
Block
Unchecked
Checked
Text
'false'
'true' |
When unchecked, erase
the logging data. The size of the database does not change.
When checked, erase the logging
data and optimize the database. |
- Logging data cannot be restored after it is erased.
Export logging data as required.
- Runtime
performance may degrade while erasing logging data. Perform
delete when starting or closing the display unit or while
the system is stopped.
- When logging data is erased, the data logging source
property [LogCount] is reset to 0.
- When logging data is erased, the trend graph switches
to real-time mode. Use the [Trend Graph] operation to
switch between modes.
|
