Trend Graph

Use trend graph operations to manipulate a trend graph.

Note:

For information on the naming convention and script keywords, refer to the following.
Naming Conventions

changeTrendGraphMode($GraphicObject.TrendGraph1);
2 1

1: Trend Graph

2: Operation

You can use these operations to perform the following:

Settings in Trend Graph:

[Mode change]	Block [Mode change] Text changeTrendGraphMode(TRENDGRAPH);	Enables changing between Historical and Real-time modes.
[Move Cursor to New data point]	Block [Move Cursor to New data point] Text moveTrendGraphCursor(TRENDGRAPH, $Enums.DataPoint.New, 1);	In historical mode, move the cursor position display forward by the specified amount.
[Move Cursor to Past data point]	Block [Move Cursor to Past data point] Text moveTrendGraphCursor(TRENDGRAPH, $Enums.DataPoint.Past, 1);	In historical mode, move the cursor position display backward by the specified amount.
[Move Graph plot to New time]	Block [Move Graph plot to New time] Text moveTrendGraphPlot(TRENDGRAPH, $Enums.GraphPoint.NewTime, 1, $Enums.Time.Day);	In historical mode, move the displayed time axis forward to the specified time.
[Move Graph plot to Past time]	Block [Move Graph plot to Past time] Text moveTrendGraphPlot(TRENDGRAPH, $Enums.GraphPoint.PastTime, 1, $Enums.Time.Day);	In historical mode, move the displayed time axis back to the specified time.
