Convert String to Numeric/Float

Converts a string to an integer (decimal, hexadecimal) or real number.

The string in [Source Data] is converted to a numerical value in the data format specified in [Source Data Format] and stored in [Destination Data].

TARGET = parseInt(EXPRESSION);
1 2 3

#	Description
1	[Destination Data] Set the destination where you want to store the converted numeric value.
2	[Source Data Format] Select one of the following formats: Block [Decimal]: Converts the string to a decimal number. [Hex]: Converts the string to a hexadecimal number. [Float]: Converts the string to a real number. Text 'parseInt': Converts the string to a decimal number. 'parseHex': Converts the string to a hexadecimal number. 'parseFloat': Converts the string to a real number.
3	[Source Data] Set the source data where the string to convert is stored.

(Example)

Var1 = parseInt(Var3);

Characters that can be converted are as follows.

Operation Example

Variable in [Source Data]	[Source Data Format]	Variable in [Destination Data]		Comments
String	[Source Data Format]	Data Type	Value to store	Comments
AA	Hex	INT	170 (0xAA)	-
AA	Dec	INT	(none)	Format error. It is judged as fail in the "Operation Result" Operation.
AG	Hex	INT	(none)	Format error. It is judged as fail in the "Operation Result" Operation.
Aa	Hex	INT	170 (0xAA)	Lowercase letters are also supported.
64	Dec	INT	64	-
64	Hex	INT	100 (0x64)	-
65535	Dec	UINT	65535	-
65535	Dec	INT	(none)	The string is not stored because the converted number has exceeded the INT variable's input range. It is judged as successful in the "Operation Result" Operation.
12.345	Float	REAL	12.345	The actual data stored may depend on the values supported by the REAL data type.
-1	Dec	INT	-1	-
FFFF	Hex	INT	-32768 (0xFFFF)	-
FFFF	Hex	UINT	65535 (0xFFFF)	-
True	-	BOOL	True	“True” is stored only if the string is “True” (exact match only). For everything else, “False” is stored.
False	-	BOOL	False	-
true	-	BOOL	False	“True” is stored only if the string is “True” (exact match only). For everything else, “False” is stored.
abc	-	BOOL	False	“True” is stored only if the string is “True” (exact match only). For everything else, “False” is stored.
